The
Model 4020 utilizes a flame ionization
detector (FID) for the continuous trace
analysis of total hydrocarbons (THC)
under a variety of different process
conditions. The principle of operation
is based on measuring the ion current
generated when organic compounds are
dissociated in an intense hydrogen flame.
The
4020 is ideal for monitoring hydrocarbon
contamination in high purity bulk gases.
When coupled with Teledyne's unique
separation column, the 4020 is also
diverse enough to be applied in hazardous
locations for the detection of volatile
hydrocarbons in cooling water for process
leak detection and environmental compliance.
Gas
Control System
- Unique
sintered stainless steel restrictors
control the flow of the sample and
support gases to provide a stable,
reproducible signal
- Temperature
controlled and insulated sample analysis
compartment enhances stable performance
- Bypass
regulator provides quick response
to process changes and is strategically
placed in the sample flow path to
eliminate sample contamination issues.
Features
- User
programmable ranges
- Standard
auto-calibration programming - ideal
for unmanned plant conditions
- Enhanced
temperature control of sample compartment
for stable, reproducible results
- Electronic
Flame Out Guard circuitry
- Stainless
steel sample system with flexible
design to handle either a 100% H2,
H2 / N2, or H2 / He support gas fuel
mixture
- Easily
accessible pressure and flow control
devices
- Slide
out chassis design provides operators
with easy access to internal components
- CE
marked
- X-purged
configurations for hazardous area
installations available
- Multiple
gas calibration not required
- Optional
rear-mounted calibration valves and
fuel solenoid for easy maintentance
Applications
- Monitoring
the purity of oxygen, argon, nitrogen
and other blanketing gases in the
manufacture of microcircuits
- Monitoring
hydrocarbon contamination in air liquefaction
and other gas production processes
- Gas
purity certification
- Detecting
trace hydrocarbons in ambient air
- Detecting
atmospheric pollutants
- Hydrocarbons
in cooling tower water for process
control leak purposes
- Monitoring
for fuel leakage or toxic solvents
- Monitoring
hydrocarbons in CO2 feed streams in
the food / beverage industry
|
